Ultralift Plus™, Magnetic Lifters
Eclipse Lifting Eye Mechanism -
guarantees the load cannot be
dropped under tension (patents
pending).
The Eclipse Ultralift Plus™ is the
only permanent magnetic lifter to
come complete with the ‘Safety
Shim’ system. (Internationally
patented).
Guarantees a 3:1 Safety Factor
irrespective of unknown
weights, poor surface condition,
thinner sections etc.
Removes all doubts and
uncertainties regarding safe lifts.
Is quick and easy to use.
|
Eclipse Lifting Eye Mechanism - guarantees the load cannot be dropped under tension (patents pending). |
|
||||
|
The Eclipse Ultralift Plus™ is the only permanent magnetic lifter to come complete with the ‘Safety Shim’ system. (Internationally patented). |
|||||
|
Guarantees a 3:1 Safety Factor irrespective of unknown weights, poor surface condition, thinner sections etc. |
|||||
|
Removes all doubts and uncertainties regarding safe lifts. |
|||||
| Is quick and easy to use. | |||||
The safety load isolator incorporated in the unique lifting eye mechanism combined with our patented ‘Safety Shim’ means that Safe just got Safer.
How easy is it to use?
The Ultralift Plus™ is so simple to use, it functions
under the
same principles as the Ultralift. Once the ‘Safety Shim’
test has
been completed you simply lower the Ultralift Plus™ onto
the
work piece, then by depressing the button on the safety handle
(like a car handbrake) the handle can be turned through 120º
until
it locks under the safety catch - the component can now be lifted.
At this stage the Lifting Eye is under tension, activating
the
operating handle isolator, guaranteeing the load cannot be dropped
by accidental switching.
| Model Number | Unit Weight |
|
|
|||
| SWL | Min. Thick | Mx Length | SWL | Max. Diameter | ||
| MAG.UL-0275P (detailed specs) | 9 lbs | 275 lbs | 0.79" | 60" | 110 lbs | 8" |
| MAG.UL-0550P (detailed specs) | 24 lbs | 550 lbs | 1" | 60" | 220 lbs | 12" |
| MAG.UL-1100P (detailed specs) | 59 lbs | 1100 lbs | 1.18" | 60" | 440 lbs | 16" |
| MAG.UL-2200P (detailed specs) | 139 lbs | 2200 lbs | 1.77" | 60" | 880 lbs | 18" |
| MAG. UL-4400P (detailed specs) | 345 lbs | 4400 lbs | 2.17 | 60" | 1760 lbs | 24" |
Question: How can I ensure a safe lift - guaranteed every time?
Answer: Simple ... use the Safety Shim to perform a quick pre-test
Lower the Ultralift Magnet
on the "Safety Shim" so that it is sandwiched between
the component and the lifting magnet.
- Turn on magnet on and lift component
20mm ( 3/4") from the ground- if it doesn't lift, then the
component is too heavy for the lifter. Try again with a larger
capacity lifter or if the component is long or thins - 2 lifters
and a spreader beam.
- Lower the component back on
the ground & turn the magnet off
- Remove the "Safety Shim"
- Put the Ultralift Magnet directly
onto the component and turn the magnet on
- Lift the component with the
required safety factor - guaranteed.
The above exercise introduces
specific air-gap for the test lift, that ensures that once it
is removed ... the required safety factor exists.
This technique is a fast and foolproof
pre-test that will guarantee safety irrespective of unknown weights,
poor surface condition, thinner sections etc.
Safety Shim is only available with
Ultralift Lifting Magnets
