Facsimile

QUICK-SETTING COMPOUND

This is classified as a hazardous material. We can only ship within the continental USA.

CLONE ANY PART QUICKLY WITH

Facsimile logo

QUICK-SETTING COMPOUND

MAKES ACCURATE REPRODUCTIONS IN 6 TO 8 MINUTES

Facsimile kits

No. FLEX.16000- Introductory Kit

Facsimile Catalog

Free 24 page applications
book available on request.
CATALOG 589-F


Facsimile is a special plastic compound kit, which is used for duplicating surface flats, roughness and for dimensional transfer of inaccessible locations. Many other applications are listed below and many more are located in our free 24 page applications booklet.

  • Make duplicates for measuring, such as gages, etc.
  • Test surface geometry, flatness, microfinish, etc.
  • Make permanent records of surface geometry, etc.
  • Make custom holding and nesting fixtures.
  • Make quick jigs.
  • Make excellent stylus patterns.
  • Cast small run parts and prototypes.
  • Mask, fill in and seal.
  • Fretting depth of blade dovetails in jet engines.
  • Make potting, bonding and repairing easy.
  • Closer inspection can be performed by allowing the casting to cure in a pressure vessel (15 p.s.i.).
  • Facsimile will not affect the surface of ferrous or nonferrous materials to which it is applied.
  • When casting in a "CONFINED" area, it is better to cast ½ of the internal shape.
  • Remember-when casting without releasing agent, an ACETONE soak removes facsimile.

AVAILABLE IN LARGER "ECONOMY" KITS

TECHNICAL DATA
A test submitted by E.I. Dupont DeNemour & company to an independent test lab showed the following properties of facsimile:

TEST PIECE APPROXIMATELY 1" ROUND BY ¼" THICKNESS…
COMPRESSION TEST…Maximum load 6,800 lbs. Compression strength 9,650 PSI.
MECHANICAL PROPERTIES…Ultimate tensile 3,415 PSI.
WATER ABSORPTION…(24 hours at 73°) 0.31% by weight.

The kit contains all materials and instructions. The facsimile can be diluted from a putty consistency to a watery consistency to best suit your job needs. If larger quantities of facsimile are desired, they can be ordered in 3lb., 25 lb., 50lb., and
100lb. Kits at proportionately lower prices per pound.

Facsimile is Made in the U.S.A.
INTRODUCTORY KIT
ONE lb. KIT NO. FLEX.16000
Complete kit contains:
FACSIMILE POWDER 1LB. Troy
1-  120cc FACSIMILE liquid
1-  60cc Flexbar Release Agent
1-  Powder Scoop
1-  Molding clay
10- Disposable cups (graduated)
10- Wooden spatulas
1-   1 0z. Polypropylene measuring cup
COMPLETE KITS*
FLEX.16000
FLEX.16003
FLEX.16025
FLEX.16050
FLEX.16100
1 LB. KIT FACSIMILE
3 LB. KIT FACSIMILE
25 LB. KIT FACSIMILE
50 LB. KIT FACSIMILE
100 LB. KIT FACSIMILE

* #FLEX.16000, One pound kit yields 20 cubic inches of solid (cured) material.
    #FLEX.16003, three pound kit yields 62 cubic inches of solid (cured) material.
                  #FLEX.16025, twenty five pound kit yields 518 cubic inches of solid (cured) material.
Our Model #FLEX.16025-Facsimile Kit contains the following:

25 lbs (Tr.) Facsimile Powder
1 gallon Facsimile Liquid
1-60cc Release Agent
1 Powder Scoop
1 Large Bar Molding Clay
10 Graduated Disposable Cups
150 Wooden Spatulas
10-6oz. Polypropylene Measuring Cups
Application Manual
